All Copper Test Fine Powder Sieve Analysis Equipment For Particle
Size Analysis
Product Introduction
DY laboratory test sieve adopts new type power generator that
generates multivariate high-frequency vibration to sieve and filter
samples efficiently.Meanwhile ,its standard screen makes sure
sample analysis of high precision .At the same time,it uses upright
motor as the source of vibration, The vertical motor, which is
installed with eccentric hammers on the top and bottom, is regarded
as vibratory source. The eccentric hammers change the track of
rotation into horizontal, vertical and inclined movement, and then
pass the movement to the sieving surface. Adjusting the phase angle
between the top and bottom eccentric weight can change trajectories
of the materials on the sieve.
Product Features
1. This test sieve shaker has low working noise(<50dB), high
efficiency, and high precision(>95%).
2. Multi-dimensional vibration can be created, making the sieving
process highly efficient.
3. The standard screen can guarantee the high precision of the
analysis.
4. A timer is available for the motors of our test sieve shaker.
Different sieves with different meshes can be used to screen a
certain kind of material for a same period of time, ensuring that
data are comparable, and the data’s error is reduced to a low
level. Thus you can access the material quality accurately by this
premium shaker.
Using Scope
For each test room, laboratory, screening, and other inspection
department of granular and powdery material particle structure,
liquid solids and debris in the precise amount of screening,
filtering, detection. The series has the advantages of low noise,
standard test , sieve filter, high precision, wide used in
metallurgy, powder, chemical, medicine, building materials,
geology, defense and other departments of the scientific research
and production, laboratory, quality inspection room.
Technical Parameters
| Diameter(mm) | Layer | Power(kw) | Speed(r/min) | Dimension(mm) | Amplitude(mm) | Noise |
| 200/300 | 1-8 | 0.125 | 1420 | 360*300*736 | ≤5mm | ≤50db |
Service
1. We guarantee the vibrating screen could meet production
technical standard and performance requirements indicated in the
contract.
2. Warranty:18 months for the machine after delivery (not including
wearing parts).
3. Provide installation files, technical data and related soft
copies or videos etc to ensure customer could install and debug by
themselves.
4. 24-hour Services. Contact us if you have any questions.
FAQ
Q: How many kinds of material are supported?
A. All stainless steel (304, 316L)
B. All copper
Q: How long is the warranty?
The warranty is 18 month (except the wearing parts includes sealing
strip, bounce ball and sieve mesh, etc.). Because different usage,
the wearing parts will have different life.
