Stainless Steel Centrifugal Wheat Flour Airflow Vibro Sifter
Machine
Working Principle
The cylinder screen mesh of this device is placed inside of the
base machine. The materials mixed with airflow and atomization pass
the screw conveyor device, then enter the net tube. The under size
materials are sprayed through the screen cloth and discharged from
the fine stuff outlet under the action of centrifugal force and
cyclone propelling power, which caused by the rotor vane inside the
net tube. The oversize material, which can not come across the net,
will be discharged through rough material outlet along inside
surface of the tube.
Main Advantages
1. Small size, stable operation, good sealed structure.
2. Single machine or multiple machinery is available.
3. The machine can be specially designed.
4 Screen mesh can be cleaned automatically by cyclone.
5. The machine has the function of re-crashing the agglomeration
materials.
6. New type roller bearing.
7. Transfer the purified air to the two ends of the device to
reduce the temperature.
8. Air-isolated layer controlled to avoid the powder entering the
bearing.
Using Scope
This machine is available in various industries such as starch,
glucose powder, xylitol, soy protein, peanut white, vitamin C,
sorbitol, ganoderma lucidum powder, malt powder, coffee powder,
bread flour, flour, spices, food additives, raw material powder,
medicine intermediates, glass beads, perlite, silicon carbide,
silica, activated carbon, epoxy, polyethylene powder, fire
extinguishing agents, zircon powder, pigment (phthalocyanine blue,
phthalocyanine green and red, phthalocyanine Qinghuang, Huang Dan,
fever ceramic pigment), magnetic materials, cobalt powder,
pyrophyllite powder, barium sulfate, lithium manganese oxide, iron
ash, silica powder, glaze, paint, pollen, dehydrated vegetables,
egg powder, milk powder, baking soda, flavor, magnesium oxide,
magnesium hydroxide, calcium oxide, silicon nitride, alumina,
molybdenum disulfide, cellulose, nano-titanium dioxide, PVC resin
powder, barium sulfate, silica powder, melon child bean gum,
calcium fluoride powder and many other powder materials.
Technical Parameters
| Model | Material | Screen mesh size (mesh) | Power (kw) |
| DYQ24-85 | SS304 | ≤300 | 2.2 |
| DYQ30-100 | SS304 | ≤200 | 3 |
| DYQ40-120 | SS304 | ≤200 | 4 |
| DYQ50-140 | SS304 | ≤200 | 5.5 |
| DYQ60-160 | SS304 | ≤200 | 7.5 |
| DYQ70-180 | SS304 | ≤200 | 11 |
FAQ
Q: How to choose the suitable machine?
a. Customers who are familiar with technical performance and
parameters can directly order.
Note: You had better send us the pictures you have ever used.
b. Customers who need us to choose the models, please follow the
information, tell us:
1) Name and feature of the raw material?
2) Aim of using: get rid of impurity, filtration, grading
3) Handling capacity: kg /h, L/h
4) The raw material size: (mesh or mm)
5) How many final materials you want, or how many layer you need?
Note: You had better send us the relevant pictures about the
details.
