Food Grade Starch Swing Tumbler Screener With Long Using Service
Product Application
Swing tumbler silica sand vibrating screen with electronic power
spin vibrator large capacity is widely used in:
1. Chemical industry: resin pigment, medicine, grease, paint,
palette, etc.
2. Abrasive material and ceramic industry: building sand, mica,
alumina, abrasive, refractory material, slurry, etc.
3. Food industry: sugar, salt, alkali, gourmet powder, starch, milk
powder, yeast powder, pollen, food additive, bean milk, juice, etc.
4. Paper-making industry: coated slurry, exhaust liquid, paper
making liquid and waste water reclamation, etc.
5. Metallurgy and mining industry: quartz sand, ore, titanium
oxide, zinc oxide, etc.
6. Mechanical industry: casting sand, powder metallurgy,
electromagnetic material and metal powder, etc.
Product Advantages
1. High efficiency, compact design and durability, any powder and
mucilage are suitable.
2. Change sieve and clean easy, operate simply.
3. The mesh is not blocked and the powder is not flying, be
screened to 500 mesh or 0.028mm.
4. Impurities coarse material discharged automatically and can
continuous operation.
5. The unique grid design, sieve for a long time, changing sieve
fast just need 3-5 minutes.
6. Small, space-saving, easy to move.
7. The screening machine can achieve the maximum five, we
recommended to use three.
Working Principle
1. The basic movement is similar to manual sieving.
2. The eccentricity from 25 to 40mm, low speed V belt drive from
120 to 360rpm. Each product's stay time can be adjusted by the 3D
movement of the swinging sieve.
3. The materials are even on the whole screen surface from the
center to periphery, therefore it spreads axially in a spiral
movement, in which the whole process of sieving the small particles
is finished.
4. The vertical and horizontal acceleration increases with the
movement of the particles.
5. The particles close to the hole size are then separated.
6. Larger particles are then transferred to the exit. There is an
adjustable device at the exit, which adjusts the flow rate. This
device is another factor that controls the stay time of the
materials.
7. This process is the same on each sieving level.
Technical Parameters
| Model | Diameter (mm) | Screening surface (m2) | Screening surface angle (degree) | Layer | Power (kw) |
| DYB-600 | 600 | 0.29 | 0.10 | 1 - 5 | 0.25 |
| DYB-1000 | 1000 | 0.71 | 0.10 | 1 - 5 | 1.5 |
| DYB-1200 | 1200 | 1.11 | 0.10 | 1 - 5 | 2.2 |
| DYB-1600 | 1600 | 1.83 | 0.10 | 1 - 5 | 4 |
| DYB-2000 | 2000 | 2.62 | 0.10 | 1 - 5 | 5.5 |
| DYB-2400 | 2400 | 3.63 | 0.10 | 1 - 4 | 5.5 |
| DYB-2600 | 2600 | 5.31 | 0.10 | 1 - 4 | 5.5 |
FAQ
1. MOQ require?
Our MOQ is 1 set.(If you need the spare parts,it is also ok.
2. Payment method?
Usually,we accept T/T,Western Union and others, we can't accept
D/P,D/A
3. How to guarantee the quality?
If any machine quality problems, we accept return cargos.
Our warrantity is 18 months, promise your 0 risks purchasing
4. Packing and Delivery
Standard export wooden case to protect the machine from demage.
If we have no stock, we will delivery within 7-20 working days.
